Nice RDF-140-20 User Manual

EN
English – 9
Optional
3~220V
1110
Standard wiring 3~380V
Delta connection
9
14
12
Six-pole plug
hh
Electronic limit switches
Limit switch housing on the mechanism
hh
Five-pole
multiple adapter
Control
connection
cable
15
Six-pole plug
Electronic limit switch housing
below
hh
Five-pole
multiple adapter
Control
connection
cable
hh
Centrale Reductiemotor Motor
X2 - J1/U 1 UST1/U
X2 - J1/V 2 UST1/V
X2 - J1/W 3 UST1/W
X2 - J6 Bevestiging draad -
X5 - J22 4 S3 - J9
X5 - J22 5 S3 - J9
X5 - J21 10
P1 -
J3/C
X5 - J21 11
P1 -
J3/NC
X5 - J20 6
E
-
J2
X5 - J20 7
E
-
J2
X5 - J19 8
E -
J4
X5 - J19 9
E -
J4
PE Geel/groen PE
13
Motor connection with
terminal block
9a
Wago terminal
AMP plug
Safety chain
Input
RS485 B
GND
RS485 A
Safety chain
Output
7 .. 18V DC
yellow
blue
black
green
red
brown
PE
3 x 380 V3x220 V

Nice RDF-140-20 Specifications

General

Brand	Nice
Model	RDF-140-20
Category	Engine
Language	English
