English – 15
Table 5 - Programmable functions
Switches 1-2 Operation
Off-Off Manual (hold-to-run)
On-Off Semiautomatic
Off-On Automatic (automatic closing)
On-On Automatic + Always Closes
Switch 3 Operation
On Condominium (not available in manual mode)
Switch 4 Operation
On Pre-ashing
Switch 5 Operation
On Closes 5 seconds after ‘Photo’ if set to ‘Automatic’ or ‘Close after Photo’ if set to
‘Semiautomatic’
Switch 6 Operation
On Safety “Photo” also when Opening
Switch 7 Operation
On Gradual Start-up
Switch 8 Operation
On Slow down
Switch 9 Operation
On Brake mode
Switch 10 Operation
Off Brake mode
Switches 1-2:
Manual
operation
the movement is only executed while the control is active (transmitter key held to run).
Semiautomatic
operation
sending a command executes the entire movement until the operating time expires or the gate trips the limit switch.
Automatic
operation
after an Open, the system pauses and then automatically Closes the gate.
Always closes
operation
follows a power failure: if, when power is restored, the control unit determines that the gate is open, it automatically
ashes the asher for ve seconds and then runs a Close cycle.
Switch 3:
Condominium
operation
when a “Step-by-Step” command is sent and the gate starts to Open, it cannot be stopped by any other “Step-by-
Step” or Open command sent by radio until it has completed.
When closing, on the other hand, sending a new Step-by-Step command will stop and reverse the movement.
Switch 4:
When a command is sent, the asher starts ashing and, after 5 seconds (2 seconds in Manual mode), the movement starts.
Switch 5:
This function, when set in Automatic mode, holds the gate open only for the time required for vehicles or pedestrians to pass through it; when
the Photo device is cleared, the movement stops and a Close movement starts after a 5 second delay.
If the functions is set in Semiautomatic mode, when the photocells are tripped while the gate is closing, automatic Close is activated with the
programmed Pause Time.
Switch 6:
The Photo function is usually active only during Close movements; if micro switch 6 is set to “ON”, tripping the photocell interrupts Open
movements too. On the other hand, in Semiautomatic or Automatic modes, the Open movement starts again as soon as the photocell clears.
Switch 7
This function activates a soft start to gate movements to prevent them moving jerkily.
Switch 8:
Slow down, which reduces the speed to 30% of its nominal value, reduces the impact force of the gate at the end of a movement.
When this function is active, you must adjust the operating Time (TL) since the start of the slow down phase is linked to this setting. Set the
TL so that the slow down starts 50-70 cm before the limit switch is tripped. The slow down function not only reduces the speed of the gate
but also the torque exerted by the motor ( by 70%). CAUTION – In automations which demand a high motor torque, setting this function can
stop the motor.
