Toona series 5
Type electromechanical gear motor for gates or doors with leaf opening
Power input 230 Vac 50 Hz 230 Vac 50 Hz 230 Vac 50 Hz 24 Vdc 24 Vdc
Maximum absorption 1,5 A 1,5 A 1,3 A 5 A 5 A
Nominal absorption 1 A 1 A 0,9 A 2 A 2,2 A
Maximum absorbed
340 W 340 W 300 W 120 W 120 W
power
Nominal absorbed
180 W 180 W 160 W 48 W 60 W
power
Capacitor incorporated 7 µF 7 µF 7 µF - -
Protection grade IP 44 IP 44 IP 44 IP 44 IP 44
Travel 540 mm 505 mm 540 mm 540 mm 540 mm
Speed loadless 0,013 m/sec 0,013 m/sec 0,016 m/sec 0,016 m/sec 0,013 m/sec
Speed loaded 0,010 m/sec 0,010 m/sec 0,012 m/sec 0,012 m/sec 0,010 m/sec
Maximum force 1800 N 1800 N 1800 N 1800 N 2200 N
Nominal force 600 N 600 N 600 N 600 N 800 N
Operating
-20 °C to +50 °C -20 °C to +50 °C -20 °C to +50 °C -20 °C to +50 °C -20 °C to +50 °C
temperature
Thermal protection 140 °C 140 °C 140 °C - -
Cycles/h at nominal force 54 54 50 95 75
Durability estimated between 80,000 and 250,000 cycles of manoeuvres according to the conditions set out in Table 2
Insulation class FFFFF
Dimensions (mm) 965 x 115 x 105 h 965 x 115 x 105 h 965 x 115 x 105 h 965 x 115 x 105 h 965 x 115 x 105 h
Weight 7 Kg 7 Kg 7 Kg 7 Kg 8 Kg
TO5015 TO5016 TO5605 TO5024 TO5024I
TECHNICAL FEATURES OF THE PRODUCT
CAUTIONS: • The technical features set out refer to an ambient temperature of 20°C (± 5°C). • Nice S.p.a. reserves the right to make alterations to the product
any time it deems it necessary, keeping the same functionality and destination of use.
Toona series 4
Type electromechanical gear motor for gates or doors with leaf opening
Power input 230 Vac 50 Hz 230 Vac 50 Hz 230 Vac 50 Hz 230 Vac 50 Hz 24 Vdc
Maximum absorption 1.5 A 1.5 A 1.5 A 1.3 A 5 A
Nominal absorption 1 A 1 A 1 A 0,9 A 2 A
Maximum absorbed power 340 W 340 W 340 W 300 W 120 W
Nominal absorbed power 180 W 180 W 180 W 160 W 48 W
Capacitor incorporated 7 µF 7 µF 7 µF 7 µF -
Protection grade IP 44 IP 44 IP 44 IP 44 IP 44
Travel 385 mm 350 mm 385 mm 385 mm 385 mm
Speed loadless 0.016 m/sec 0.016 m/sec 0.013 m/sec 0.016 m/sec 0.016 m/sec
Speed loaded 0,012 m/sec 0,012 m/sec 0,010 m/sec 0,012 m/sec 0,012 m/sec
Maximum force 1800 N 1800 N 1800 N 1800 N 1800 N
Nominal force 600 N 600 N 600 N 600 N 600 N
Operating temperature -20 °C to +50 °C -20 °C to +50 °C -20 °C to +50 °C -20 °C to +50 °C -20 °C to +50 °C
Thermal protection 140 °C 140 °C 140 °C 140 °C -
Cycles/h at nominal force 58 58 54 50 95
Durability estimated between 80,000 and 250,000 cycles of manoeuvres according to the conditions set out in Table 2
Insulation class FFFFF
Dimensions (mm) 820 x 115 x 105 h 820 x 115 x 105 h 820 x 115 x 105 h 820 x 115 x 105 h 820 x 115 x 105 h
Weight 6 Kg 6 Kg 6 Kg 6 Kg 6 Kg
TO4005 TO4006 TO4015 TO4605 TO4024
