English – 28
10
BASIC TROUBLESHOOTING...
In case of malfunction due to problems during installation or failure of parts, refer to table 6:
Table 6
OK LED Problem Solution
Off Fault Check for presence of the power supply; check that the fuses are
not blown; if necessary, identify the cause of the fault and then re-
place them with fuses with the same specications.
On Serious malfunction There is a serious malfunction; try switching off the control unit for a
few seconds; if the condition persists, it means there is a malfunction
and the circuit board has to be replaced
1 ash per second All OK Normal operation of control unit
2 quick ashes The status of the inputs has changed This is normal when there is a change in one of the inputs: Step-by-
step, Open, Close, Stop, Photo / Photo2 or a command is received
from the radio transmitter
STOP LED Problem Solution
Off Intervention of one of the devices con-
nected to the STOP input
Check the devices connected to the STOP input
On All OK Stop Input active
FOTO LED Problem Solution
Off Intervention of one of the devices con-
nected to the PHOTO input
Check the devices connected to the PHOTO input
On All OK Photo Input active
PHOTO 2 LED Problem Solution
Off Intervention of one of the devices con-
nected to the PHOTO 2 input
Check the devices connected to the PHOTO 2 input
On All OK Photo 2 Input active
STEP-BY-STEP LED Problem Solution
Off All OK Step-by-Step input inactive
On Intervention of Step-by-Step input It is normal if the one of the devices connected to the Step-by-Step
input is active
LED OPEN Problem Solution
Off All OK Open input not active
On Intervention of Open input It is normal if the one of the devices connected to the Open input
is active
LED CLOSE Problem Solution
Off All OK Close input not active
On Intervention of Close input It is normal if the one of the devices connected to the Close input
is active
9
DISPOSAL OF THE PRODUCT
This product constitutes an integral part of the automation system, therefore it must be disposed of together with the former.
As in installation, also at the end of product lifetime, the disassembly and scrapping operations must be performed by qualied personnel.
This product is made up of different types of material, some of which can be recycled while others must be disposed of. Seek information on the
recycling and disposal systems envisaged by the local regulations in your area for this product category.
CAUTION! - Some parts of the product may contain polluting or hazardous substances which, if disposed of into the environ-
ment, constitute serious environmental and health risks.
As indicated by the symbol, the product may not be disposed of as domestic waste. Sort the materials for disposal, according
to the methods envisaged by current legislation in your area, or return the product to the retailer when purchasing an equivalent
product.
CAUTION! - Local legislation may include the application of serious nes in the event of improper disposal of this
product.
CAUTION! – Even if discharged, batteries can contain pollutant substances and therefore must NEVER be disposed of in com-
mon waste collection points. Dispose of them according to separate waste collection methods as envisaged by current local
standards.
