Screen Descriptions
Manual # 42-02-1P28 A3 5-17
5
Recall
Switches
Motion 2000 TS provides four car recall inputs, Recall S1 - S4. For momen-
tary input activation, set latch timer
- Latch Switch(1-4): (Seconds) At recall floor, car will wait for this period of time
for an initiating action to be taken (i.e., independent control initiated, access
operation initiated, etc.) before automatically returning to normal passenger ser-
vice (0 sec. for continuous input)
- Recall Floor (1-4): Set to desired recall floor
- RECALL Sn: INDEPENDENT(1-4): (Yes/No) When set to YES, the car will go
into independent service when recall is complete.
- Override Security (1-4): (Yes/No) If Yes, the recall operation will override
security settings for the floor
- Car Calls Disposition (1-4): How should registered car calls be handled before
the car recalls? (Cancel Calls/Answer Calls/Allow New Calls/Cancel Calls at Next
Stop)
- Door Operation (1-4): (Cycle Doors/Doors Closed/Doors Open) Determines
door action on arrival at recall floor
- Override IND (1-4): (Yes/No) If Yes, recall operation will override Independent
service
- Override ATS (1-4): (Yes/No) If Yes, recall operation will override Attendant
Service
Network
Settings
- IP Address: IP address of car on LAN
- Subnet Mask: Subnet mask of car on LAN
- Default Gateway: Default gateway of car on LAN
CFSS Commandeer for Special Service- CFSS Medical Emergency: (Yes/No)
- CFSS Light Flash: (No flash, CFSS I, CFSS II OR CFSS I AND CFSS II)
- CFSS Car Call Disposition: (Cancel calls, answer calls, allow new calls, or can-
cel at next stop)
- CFSS Recall Timer: (0-1800 sec.)
- CFSS BYPASS IND TIMER: Cars on Independent Service are eligible for CFSS
calls if this timer is set to a non-zero value and may be assigned a CFSS call.
Independent Service is bypassed and CFSS recall initiated once this timer has
expired. Until then, the car remains on Independent Service. (0-1800
sec.)(0=off and 1800 sec.=30 min.)
- CFSS BYPASS ATS TIMER: Cars on Attendant Service are eligible for CFSS calls
if this timer is set to a non-zero value and may be assigned a CFSS call. Atten-
dant Service is bypassed and CFSS recall initiated once this timer has expired.
Until then, the car remains on Attendant Service. (0-1800 sec.)(0=off and 1800
sec.=30 min.)
- CFSS I Front/Rear Opening: (Door settings)
- CFSS I Front/Rear Closing: (Door settings)
- CFSS II Front/Rear Opening: (Door settings)
- CFSS II Front/Rear Closing: (Door settings)
- CFSS II Switch Type: (Constant, momentary, none)
- CFSS II Without Recall First: (Yes/No)
- CFSS II Front/Rear Autoclose CC: (Yes/No)
- CFSS In-Car On Timer: (0-1800 sec.)
- CFSS In-Car Off Timer: (0-1800 sec.)
- CFSS II Front/Rear Autoclose CC: (Yes/No)
Table 5.2 Touchscreen Organization and Content
Tab Subtab Description
CONFIG 03
