The Computer
5-16 Manual # 42-02-1P28 A3
Building
Security
- Security Enabled: (Yes/No) If Yes, enables car call security. Valid credential
must be recognized by security system and Car Call Enable signal issued to con-
troller before call may be registered
- DEDICATED UIO CALL ENABLE: (NONE, CAR, HALL, CAR, HALL) Used when
the security hall call enable inputs are dedicated on the UIO board.
- CC Enable Inputs Polarity: (ACTIVE HIGH, ACTIVE LOW) If ACTIVE HIGH, a
high state of the car call enable signal is required to register car calls. If ACTIVE
LOW, a low state of the car call enable signal is required to register car calls.
- HC Enable Inputs Polarity: (ACTIVE HIGH, ACTIVE LOW) If ACTIVE HIGH, a
high state of the hall call enable signal is required to register hall calls. If ACTIVE
LOW, a low state of the hall call enable signal is required to register hall calls.
- Enable DOB on Security: (Yes/No) If yes, the Door Open Button is functional at
a secured floor. (Prior access required)
- IND Overrides Security: (Yes/No) If yes, Independent operation overrides
security.
- ATS Overrides Security: (Yes/No) If yes, Attendant Service overrides security.
- Remote CC. Override CCSEC: If YES, remote calls override security (includes
call registration panel in OBD)
- Park at CC Secured Floor: (Yes, No) If YES, the car is allowed to park at a
secured car call floor.- SEC. Bracelet (A-H) Floor: (None, 1-16)
- SEC. Bracelet (A-H) Side: (None, Front, Rear, Both)
- Allow CC at SECBRAC Floor: (Yes/No)
NOTE: Security Bracelet inputs are used for wandering patients and child
abduction features.
Emergency
Power
- Emergency Power Type: None (No emergency power available), Dispatcher
(Emergency recall and run determined by dispatcher), Overlay (Emergency recall
and run determined through discrete I/O by emergency power overlay system)
- Cars to Recall/Run on EP:* Number of cars able to run on emergency power
- EP Delay Timer:* (2-600 Sec.) delay before running EP logic on generator
power
- Pref. Car to Recall First:* (Car ID1 or Car ID2)
- Pref Car to Run on EP2:* (EP AUTO) Select car to run on emergency power
(Last recalled, Car ID1, Car ID2)
- Bypass EP Sequencing:* When set to Yes, emergency power recall and select
to run phases are bypassed and the maximum number of cars are selected to run
on generator power without need of an EP selection switch
- EP Recall Floor: Floor to which cars will recall on emergency power
- EP Door Operation (Front/Rear): Open Doors (DEFAULT) (Doors open at
recall floor), Close Doors (Doors remain closed at recall floor), Cycle Doors
(Doors will cycle open and then close at recall floor)
-EP Recall Timeout: Seconds dispatcher should attempt to recall non-responsive
car before passing it by
*These parameters are controller by the dispatcher.
Table 5.2 Touchscreen Organization and Content
Tab Subtab Description
CONFIG 03
