Screen Descriptions
Manual # 42-02-1P28 A3 5-15
5
NTS
Switches
- U/DSL (1,3,4) Option: Virtual, Physical, or Disabled
- USL (1,3,4) Distance: Programmed distance at which the virtual USL2 switch is
positioned from terminal floor level. Distance should be set to the same value as
Floor Step Up (top floor) distance.
- DSL (1,3,4) Distance: Programmed distance at which the virtual DSL2 switch is
positioned from terminal floor level. Distance should be set to the same value as
Floor Step Down 1 distance.
System
Control
Parameters
- Number of Starters: (1-3)
- Min. Number of Starters: (1-3)
- Starting Control Type: Sequential / Simultaneous
- Soft Stop Delay: When set, if the start contact signal is removed, the starter will
continue to operate normally for this additional time to allow a hydraulic valve to
close before motor shutdown. After timer expires, the starter will shut down nor-
mally. Set to 0.0 to disable
- Starter Type: (1-3) Across the Line, WYE-Delta, Siemens, or Sprecher and
Schuh
- Starter M Contactor: (1-3) (Yes/No)
- Starter Up to Speed: (1-3) (Min . 50 Max 6.50 Default 1.)
- Up to Speed Delay: (1-3) Set the amount of time that the controller will wait to
allow the motor to accelerate to nominal speed. Set to 0.0 to disable. Max is 15
seconds
- Starter W-D Transition: (1-3) (0.05 to 0.50 seconds timer)
- Valve Type: Standard, TKE/Dover, Pilot Relays, or Bucher
- Contract Speed: Set to contract speed for car
- Relevel Distance: After initial leveling into the floor, defines the distance on
either side of level which the car can drift before releveling is activated. Must
always be greater than Dead Zone Distance
- Level Dead Zone Distance: When moving normally between floors or correct-
ing to a floor from beyond 6 inches, it defines the distance on either side of exact
level at which the stop command is issued to coast into the floor. Start with 0.5
inches
- Relevel Dead Zone Distance: When correcting to a floor from within 6 inches
(releveling to a floor), it defines the distance on either side of exact level at
which the stop command is issued to coast into the floor.
- Slow Inspection Speed: (Yes/No)
Table 5.2 Touchscreen Organization and Content
Tab Subtab Description
CONFIG 02
