The Computer
5-14 Manual # 42-02-1P28 A3
Door
Operation
- Manual Doors: (None, Front, Rear, Both) Set for fully manual freight doors
- Mechanically Coupled: (None, Front, Rear, Both) Set for the mechanically cou-
pled doors
- Vertically Sliding (None, Front, Rear, Both) Set for the vertically sliding doors.
- DOOR POSITION MONITOR: (Front, Rear, Both, None) Used to specify the
side where the door position monitor switch is installed.
- Use GS+DCAB for DCL: (None, Front, Rear, Both) Used when the door close
limit switch is not used. Instead, the DCL status is internally set by looking at the
GS/GSR and DCAB/DCABR statuses
- Pre-Open Doors: (Yes/No) If yes, doors will begin preopening when car is within
three inches of the destination door zone
- NUDGING: (Yes/No) Enable or Disable for both sides
- DOOR CLOSE WARNING FRONT: (NONE , ALWAYS – IF CLOSED WITH HALL
DCB) Set if it is required to delay the front door closing of power operated auto-
matic doors and if a door closing warning buzzer and/or light are required before
the doors start to close.
- DOOR CLOSE WARNING REAR: (NONE , ALWAYS – IF CLOSED WITH HALL
DCB) Set if it is required to delay the front door closing of power operated auto-
matic doors and if a door closing warning buzzer and/or light are required before
the doors start to close.
- DC WARNING LIGHT TIMER: (OFF 0 - 1 sec. to 30 min.) Default: 5 sec. Set for
the time the door close warning light is to come ON before the doors start to
close.
- DC WARNING BUZZER TIMER: (OFF 0 - 1 sec. to 30 min.) Default: 2 sec.
- Open Gate If Hoistway Open: (None, Front, Rear, Both) Set when it is required
to keep the car gate open if the hoistway doors are open.
- Sequential Door Open (None, front, rear): If set to front/rear, that side will
open/close first when demand exists for both sides to open at a walk-through
floor. Only one side will open and close at a time for this feature
- Idle Door Open: (None, Front, Rear, Both) Used to specify which doors are to
open or remain open when idle or parked at a floor
- Latch Door Open: (None, Front, Rear, Both) Used to keep the Door Open Func-
tion (DOF) on, even when the specified side doors are fully open.
- Latch Door Close: (None, Front, Rear, Both) Used to keep the Door Close Func-
tion (DCF) on, even when the specified side doors are fully closed.
- Passenger Front/Rear Opening: Auto, Constant on DOB, Momentary on DOB,
Not controlled by MCE
- Passenger Front/Rear Closing: Auto, Constant on DCB, Constant on DCB OR
CC, Constant on DCB IF CC, Constant on Car Call, Momentary on DCB, Momen-
tary on DCB IF CC, Not controlled by MCE
- Passenger Front/Rear Autoclose CC: Yes/No
- IND Front/Rear Opening: Auto, Constant on DOB, Momentary on DOB, Not
controlled by MCE
- IND Front/Rear Closing: Constant on DCB, Constant on DCB OR CC, Constant
on DCB IF CC, Constant on Car Call, Momentary on DCB Not controlled by MCE
- IND Front/Rear Autoclose CC: Yes/No
- ATS Front/Rear Opening: Auto, Constant on DOB, Momentary on DOB, Not
controlled by MCE
- ATS Front/Rear Closing: Constant on DCB, Constant on DCB OR CC, Constant
on DCB IF CC, Constant on Car Call, Momentary on DCB Not controlled by MCE
- ATS Front/Rear Autoclose CC: Yes/No
- EMSI Front/Rear Opening: Automatic, Constant on DOB, Momentary on DOB,
Not Controlled by MCE
- EMSTI Front/Rear Closing: Automatic, Constant on DCB, Constant on DCB OR
CC, Constant on DCB IF CC, Constant on Car Call, Momentary on DCB, Momen-
Table 5.2 Touchscreen Organization and Content
Tab Subtab Description
