Screen Descriptions
Manual # 42-02-1P28 A3 5-13
Hoistway
Setup
- LS-EDGE Landing system only. Floor heights are set during hoistway learn
operation but may be adjusted here to compensate for floor level magnet position
imperfections
- Floor Height (n): Level at floor height in inches for each landing
- Floor Offset (n): Moves the floor up or down (negative entries) to adjust the
elevator level position.
- Stepping Type: Single Step or Dual Step
- Floor Step Up (n): Sets the distance from floor level at which the virtual step-
ping magnets will force high speed to drop when the elevator is running up to
that floor
- Floor Step Down (n): Sets the distance from floor level at which the virtual
stepping magnets will force high speed to drop when the elevator is running
down to that floor. Please refer to “Initial Stepping Positions” on page 3-19.
- Floor Sub-Step Up (n) Set for Dual Step
- Floor Sub-Step Down (n) Set for Dual Step
- Landing System ID: Automatically entered during hoistway learn operation.
Forces a new learn if the landing system software or hardware is changed
- Top Access Distance: Sets the location of the “top access switch” that limits
downward travel to a point at which the crosshead is level with the sill when
accessing the car top
- Bottom Access Distance: Sets the location of the “bottom access switch” that
limits upward travel to a point at which the bottom of the apron is even with the
hoistway entrance header
- Top/Bottom Access Margin
- U/DTL Limit Opt: Virtual, Physical, or Disable
- U/DTL Distance: MIN: 0.0, MAX: 1200.0, VAL: 2.0
ETS
Switches
- N/A for Hydraulic Elevator
NTS
Switches
- U/DSL (1,3,4) Option
- USL (1,3,4) Distance: Programmed distance at which the virtual USL2 switch is
positioned from terminal floor level. Distance should be set to the same value as
Floor Step Up (top floor) distance.
- DSL (1,3,4) Distance: Programmed distance at which the virtual DSL2 switch is
positioned from terminal floor level. Distance should be set to the same value as
Floor Step Down 1 distance.
Table 5.2 Touchscreen Organization and Content
Tab Subtab Description
