The Computer
5-12 Manual # 42-02-1P28 A3
System
Timers
- Motor/Valve Time Limit (Default 3 minutes) Starts when the controller
attempts to move the car in the up direction and resets when the car reaches its
destination floor. If the timer expires before the car reaches its destination, the
controller stops trying to move the car up to protect the motor. The car will then
lower to the bottom floor and shut down
- Open Limit Time (Default 10 seconds) Determines how long the door operator
should attempt to open the doors before declaring an unsuccessful attempt (Door
Open Fail 1 - 3). After 3 unsuccessful attempts, a Door Open Fault will be
declared. This action protects the door motor
- Close Limit Time (Default 10 seconds) Determines how long the door operator
should attempt to close the doors before declaring an unsuccessful attempt (Door
Close Fail 1-3) After 3 unsuccessful attempts, a Door Close Fault will be gener-
ated, followed by a Door Fault Shutdown. This actions protects the door motor
- Door Interlock Timer (Default 100 ms) Introduces a delay when closing or
opening doors that are abruptly reversed. This may be required if the door oper-
ator is sensitive to such reversal due to debounce capability. Set to 0.0 if not
required
- Short Door Timer (Default 1 second) Length of time doors will remain open
after being reopened by photo eye, safety edge, or door open button
- Car Call Timer (Default 2 seconds) Length of time doors will remain open to ser-
vice a car call
- Hall Call Timer (Default 4 seconds) Length of time doors will remain open to
open to service a hall call
- Lobby Call Timer (Default 6 seconds) Length of time doors will remain open to
service a lobby call
- ADA Car Timer (Default 3 seconds Length of time doors will remain open to ser-
vice an ADA car call
- ADA Hall Timer (Default 5 seconds) Length of time doors will remain open to
service an ADA hall call
- Stuck PHE Timer (Default 10 seconds) Length of time the photo eye is allowed
to delay closing before it is bypassed and the doors begin to close
- Stuck SE Timer (Default 20 seconds)
Length of time the safety edge is allowed to delay closing before it is bypassed
and the doors begin to close
- Stuck DOB Timer (Default 10 seconds) Length of time the door open button is
allowed to delay closing before it is bypassed and the doors begin to close.
- Car Delayed Timer (Default 30 seconds) Removes the car from hall call demand
if delayed beyond the timer setting
System
Timers
- COS Timer (Default 5 minutes) If the car delayed condition persists for the
amount of time set here, the car will be removed from service for all calls (COS =
Car Out of Service)
- FLO Timer (Default 5 minutes) When a car is inactive for this amount of time,
the fan and light in the cab will automatically be turned off. (Disabled on Inspec-
tion)
- Door Hold Timer (Default 20 seconds) Time to hold the doors open for a
momentary activation of the Door Hold input (button).
- Parking Timer (Default 2 seconds) If a car is idle in excess of the time set here,
it will move to its designated parking floor
- Sleep Mode Timer (Default 10 minutes) The touch screen will enter sleep mode
when this timer expires if there has been no activity
- EMERG DISP. Hold Timer: The amount of time between EMERGDISP run trip
cycles
Table 5.2 Touchscreen Organization and Content
Tab Subtab Description
