Screen Descriptions
Manual # 42-02-1P28 A3 5-11
Elevator
Features
- ATS Open Side (None, front, rear, both): Which doors to open when Attendant
Service switch is initially turned on
- ATS Stop Cancels CC (Yes/No): If Yes, cancels remaining car call at first car call
stop.
- Autostop Floor (1-16): The floor the car will stop at when Autostop function is
enabled
- Autostop Direction (Up, down, both): The specified direction that the car will
stop at the Autostop floor
- Autostop Open Side (Front, rear, both): Which doors will open at the Autostop
floor
- Autostop Dwell Time: Door Dwell timing at Autostop floor
- Exercise Timer (0-24 hours): How often to initiate exercise operation
- Exercise Cycles (1-5): How many exercise runs to complete for each exercise
interval
- EMERGDISP Cycles (1-10): The number of emergency dispatch trips the car will
make between the timed HOLD cycles
- PI Outputs Type: Defines the usage for PI BIN 0 through PI BIN 3 outputs
(Only on MPU-B 20.01.xx or lower.)
Configure
Spare
Inputs
Allows input signals to be assigned to available spare inputs. Maximum 70. See
Spare Inputs on page 5-25
Configure
Spare
Outputs
Allows output signals to be assigned to available spare outputs. Maximum 40. See
Spare Outputs on page 5-28
Input/Output Assignment
1. Touch the input you want to configure. An assignment screen will appear.
2. Touch and highlight either the input/output you want to assign or the physical connection you
want to assign to.
2. Change selection by scrolling up or down (scroll bar on the right).
3. When desired Inputs/Outputs and desired physical connections are aligned, press OK to return
to the configure screen. Press Save to save changes.
NOTE: An input assigned to a terminal must be cleared and saved as “Not Used” before
it can be reallocated.
Table 5.2 Touchscreen Organization and Content
Tab Subtab Description
