The Computer
5-10 Manual # 42-02-1P28 A3
Elevator
Features
- PHE Cancels CCT (Yes/No) If Yes, photo eye activation cancels the active car call
dwell timer
- PHE Cancels HCT (Yes/No) If Yes, photo eye activation cancels the active hall
call dwell timer
- PHE Cancels LOT (Yes/No) If Yes, photo eye activation will cancel the lobby door
dwell timer
- CCB Cancels CCT (Yes/No) If Yes, pressing a car call button while the doors are
open will cancel normal car call door dwell time and cause the doors to begin
closing
- CCB Cancels HCT (Yes/No)
If Yes, pressing a car call button cancels the active hall call dwell timer and begin
closing doors immediately
- CCB Cancels LOT (Yes/No)
If Yes, pressing a car call button will cancel the lobby door dwell timer and begin
closing doors immediately
- DCB Cancels All Dwells (NONE, FRONT, REAR, BOTH) When set to any setting
other than NONE, all configured side(s) Dwell times are canceled when the Door
Close Button is pressed, and the related side doors shall immediately close if
there are no other door open intents.
- PHE Cancels All Dwells (NONE, FRONT, REAR, BOTH) When set to any setting
other than NONE, all configured side(s) Dwell times are canceled, and a new
Short Dwell time activated when the Photo Eye is interrupted. The related side
doors shall close when the Short Dwell time has expired and there are no other
door open intents.
- CCB Cancels All Dwells (NONE, FRONT, REAR, BOTH) When set to any setting
other than NONE, all configured side(s) Dwell times are canceled when a Car Call
Button is pressed, and the related side doors shall immediately close if there are
no other door open intents.
- Stuck Insp Input (TSSA) (Yes/No): If Yes, and if any inspection direction or
enable inputs remain high for more than one second during passenger operation,
or during inspection operation, if any combination of inspection inputs remain
high for more than five seconds, except for Enable plus Up (e.g., ICEN + ICPU)
and Enable plus Down (e.g., ICEN + ICPD), a stuck inspection button fault will be
generated.
- CP Close Bypass PHE (Yes/No): Set to Yes for the photo eye to be bypassed
during constant pressure close operation. (This option does not apply to Fire
Phase II.)
- Resynchronization Days (Sunday through Saturday): Day(s) on which jack
resynchronization is to be performed
Note: Set day of the week (UTILS > DATE AND TIME)
- Resynchronization Time (Hour: Minute AM/PM): Time at which resynchroniza-
tion is to be performed
- IND Open Side (none, front, rear, both) Which doors to open when Independent
Service switch is initially turned on
- IND Stop Cancels CC (Yes/No): If Yes, cancels remaining car calls at first car
call stop
Table 5.2 Touchscreen Organization and Content
Tab Subtab Description
