Nidec NE300 Series - Product Series

NE200&300 Quick Start Guide
7
2.3 Product Series
2.3.1 NE200 Product Series
 NE200−4T□□□□GB Three-phase 400V Constant torque/heavy-duty
application
Power （ kW ） 0.75 1.5 2.2 4.0
Adapted motor (kW) 0.75 1.5 2.2 4.0
Output
Voltage (V) 3phase 0~rated input voltage
Rated current (A) 2.5 4.0 6.0 9.0
Overload
capability
150% 1min; 180% 20sec.
Input
Rated voltage/
frequency
3phase 380V/440V; 50Hz/60Hz
Voltage range
304V~456V; voltage imbalance ≤3%; Allowable
frequency fluctuation ±5%
Rated current (A) 3.7 5.4 7.0 10.7
Braking unit Inbuilt as standard
IP rating IP20
Cooling Forced air cooling
 NE200−4T□□□□PB Three-phase 400V Variable torque/normal-duty
application
Power （ kW ） 1.5 2.2 4.0 5.5
Adapted motor (kW) 1.5 2.2 4.0 5.5
Output
Voltage (V) 3phase 0~rated input voltage
Rated current (A) 4.0 6.0 9.0 13
Overload
capability
120% 1min; 150% 1sec.
Input
Rated voltage/
frequency
3phase 380V/440V; 50Hz/60Hz
Voltage range
304V~456V; voltage imbalance ≤3%; Allowable
frequency fluctuation ±5%
Rated current (A) 5.4 7.0 10.7 15.5
Braking unit Inbuilt as standard
IP rating IP20
Cooling Forced air cooling
