8.3 CTScope
CTScope is a software application which provides commonly used oscilloscope features to monitor
drive parameters.
Features include:
• Four channels
• Triggers
• Start/Stop at absolute time
• Start/Stop on value (rising/falling edge)
• Channels can capture parameter values from different nodes
• Scaling & offset per channel
• Cursors to aid measurement
• Zoom facility
• Scroll/Panning facility
• Save/load scope configurations with or without data
• Print facility
8.3.1 Configuration
All the appropriate configuration settings are displayed on the main screen. (CT-TCP/IP must be
selected in the Communication Settings).
8.4 SyPTPro
SyPTPro is a complete integrated development suite for distributed drive applications. SyPTPro
allows user programs to be developed for multiple nodes in DPL, ladder and function block
programming languages. DPL (Drive Programming Language) is a high level language as easy to
use as BASIC but optimized for drive applications. SyPTPro also allows user programs to be
downloaded to nodes and the runtime operation of the programs to be monitored.
To use SyPTPro over Ethernet requires a version that provides Ethernet support, SyPTPro
V02.01.00 or later includes support for TCP/IP.
For more information on using SyPTPro please refer to the online help supplied.
SyPTPro can only be used to program a SI-Applications Plus option module and not an
onboard drive program or a MCi200/MCi210 Machine Controller module.
SyPTPro is only supported on the onboard Ethernet.
