36
Model FH94 Electric
III. OPERATION
FH94E
Parts Listing
28496 AIR BOX (LH & RH SIDE ARE THE SAME)
22626 AIR TUBE MANIFOLD (LEFT)
23333 AIR TUBE MANIFOLD (RIGHT)
25977 FLEXIBLE CONNECTOR (3/4 X 11") LH & RH SIDE ARE THE SAME
26606 BLOWER (LH & RH SIDE ARE THE SAME)
22995 RESTRICTOR 3/16" (LH & RH SIDE ARE THE SAME)
Air System
28531 ELEMENT, 380V, 1000W
15650 WARMER ELEMENT - 220V - 900W
26673 CONTACTOR
19161 CIRCUIT BREAKER, 3POLE, 25A
11965 CIRCUIT BREAKER, 20A
15329 SOLID STATE RELAY, 50A
27319 POWER SUPPLY, DC
27305 MAIN ON/OFF SWITCH
26600 RELAY, 250VAC, 24VDC COIL, 8A, 8 PIN
18092 RELAY BASE, 8 PIN
27774 TOUCH SCREEN, DISPLAY
26524 MOTHER BOARD
26522 MOTOR BOARD
27006 CAT 5 CABLE
15576 TEMPERATURE PROBE 4" (QTY 2)
16313 TEMPERATURE PROBE 8.5" (QTY 2)
27302 PROBE CLIP / CONNECTOR
25851 TERMINAL BLOCK - MAIN POWER & ELEMENTS
25852 END COVER - TEMINAL BLOCK
4405-18 TERMINAL BLOCK - GROUND - MAIN POWER
18686 TERMINAL BLOCK-GRAY
18687 END COVER - TEMINAL BLOCK
Electrical Elements & Controls
Belt Drive System & Bearings
29387 BELT REFLECTOR V3 PLATE (QTY 2 - LH & RH SIDE ARE THE SAME)
6027 # 35 DRIVE CHAIN (SOLD PER/FT)
6048 MASTER LINK
6035 13" ROD BELT (5FT EACH SIDE)
6046 PTFE BEARING (DISCHARGE OUTER DRIVE SHAFT)
6047 PTFE BEARING (DISCHARGE INNER DRIVE SHAFT)
6049 PTFE BEARING (FEED END - QTY 2)
19610 BEARING BLOCK, CENTER, ALUM/BRZ
26490 GEAR MOTOR,DC,BRUSHLESS (QTY 2)
26846 MOTOR CONTROL CABLE
17899 MOTOR SPROCKET - 10T
13699 DRIVE SPROCKET -32T
6037 IDLER SHAFT SPROCKET, 35B15, 5/8" BORE
18997 OUTER DRIVE SHAFT
35900 FLANGED BUSHING - INSIDE OUTER DRIVE SHAFT
19862 INNER DRIVE SHAFT
15565 IDLER SHAFT - 13"
25847 STRIPPER BLADE 13" & 13"
16402 MOUNTING BRACKET - STRIPPER BLADE - LH
16403 MOUNTING BRACKET - STRIPPER BLADE - RH
27324 CROSS ROD - TENSION SHAFT
6028 SET COLLAR - 5/8"
19912 BRACKET - U - TENSION SHAFT
Miscellaneous
25806 INCENDALYST, 8" X 15"
25333 SHAFT CLEANING TOOL
25332 TOLL, COMBINATION WRENCH
23307 CLEANING BRUSH
9133 ROD BELT PLIERS
To Next Page
