Nieco FH94E - Page 37

37
Model FH94 Electric
III. OPERATION
FH94E
Parts Listing
FeederSheet Metal Parts
27881 FEED END HEAT SHIELD
28521 FEED END GREASE PAN
27932 HEAT SHIELD - REAR
28547 DISCHARGE AWNING, PERF
27982 SLIDE - 4 LANE
27985 PTFE SHEET, FOR SLIDE
27984 CLAMP, PTFE BRACKET
17347 WING NUT (QTY 3)
27994 TRAY, GREASE, STRIPPER TO SLUDGE TRAY TRANSITION
27949 SLUDGE TRAY
22898 HOTEL PAN (1/9" X 4")
28898 FRAME SUPPORT - HOLDING PAN - 4 LANE
27882 GREASE DRIP TRAY - BOTTOM
28525 HOOD / CHIMNEY
28478 TOP COVER, BOH (QTY 2 - LH & RH SIDE ARE THE SAME)
29261 BL LOGO, BOH (QTY 2)
28479 COVER, BOTTOM RH SIDE, BOH
28480 COVER, BOTTOM LH SIDE, BOH
27922 COVER, CENTER, LH & RH SIDE, BOH
27822 LOWER SHELF, SQUARE STAND
28470 BRACKET, STACKING PHU PAN, FOR SQUARE STAND
29026 FEEDER COVER
22295 ENCLOSURE
22348 DRIVE UNIT PUSH BAR - LH
22354 DRIVE UNIT PUSH BAR - RH
15617 FEEDER BAR - 13"
11381-6 FEEDER CHAIN, CUT TO LENGTH (QTY 6 PER ASSEMBLY)
11478 FLANGE BUSHING - PUSHBAR FEEDER
22296 TENSIONER BRACKET - PUSHBAR FEEDER LH
22297 TENSIONER BRACKET - PUSHBAR FEEDER RH
28542 PATTY GUIDE, (LH & RH ARE THE SAME)
20504 CLUTCH COVER
17494 CLUTCH RESTRAINT BRACKET
15882 COMPLETE CLUTCH ASSEMBLY
14900 COMBO CLUTCH - ONLY -
14896 BEARING / SHOULDER WASHER-WHITE- (CLUTCH ASSEMBLY)
10275 THRUST WASHER
10627 BEARING CLIP
11608 BLACK KNOB - CLUTCH ASSEMBLY
27940 FEEDER MOUNTING BRACKET - RH
27941 FEEDER MOUNTING BRACKET - LH
27898 BRACKET, CLUTCH MOUNTING
