Monitoring Parameters
G r o u p D - M o n i t o r i n g P a r a m e t e r G r o u p a n d F a u l t R e c o r d
d-00
0.00 ~ Max Output FrequencyOutput Frequency
0.01Hz
0
◆
d-01
0.00 ~ Max Output FrequencySet Frequency
0.01Hz
0
◆
d-02
0～999VOutput Voltage
1V
0
◆
d-03
0～999VBus Vol tage (V)
1V
0
◆
d-04
0.0～6000.0AOutput Current
0.1A
0
◆
d-05
0～36000（RPM/min）Motor speed (RPM/min)
1
0
◆
d-06
0.00V/0.00mA～10.00V/20.00mAAnalog Input AI1 (V/mA)
0.01
0
◆
d-07
0.00～10.00V
Analog Input AI2 (V)
(Reserved)
0.01V
0
◆
d-08
0.00～10.00V
Analog Output AO1 (V/
MA) (Reserved)
0.01V
0
◆
d-09
0～60.00KHz
Pulse Input Frequency
(Khz) (Reserved)
0.01KHz
0KHz
◆
d-10
0.00～10.00VPID Setpoint (V)
0.01V
0.00
◆
d-11
0.00～10.00VPID Feedback (V)
0.01V
0.00
◆
d-12
0～65535
Current Count Value
(Reserved)
1
0
◆
d-13
0～65535S
Current Timing Value (S)
(Reserved)
1S
0
◆
d-14
0 ~ FH
Note: When expanded into binary, it means
from high to low
Sub-X4/X3/X2/X
Input Terminal Status
1
0
◆
d-15
0 ~ 1H
Note: 1 indicates that output terminal Y
is active
Output Terminal Status
1
0
◆
d-16
0.0℃～+110.0℃
Module temperature ℃
0.1℃
0
◆
d-17
0 ~ FFFFH
BIT0: Run/Stop BIT1: Forward/Reverse
BIT2: Inching
BIT3: DC braking
BIT4: Reserved
BIT5: Overvoltage Limit
BIT6: Constant Speed Down
BIT7: Overcurrent Limit
BIT8 ~ 9: 00-Zero Speed/01-Acceleration/10
-Deceleration/11-Uniform
BIT10: Overload Prealarm
BIT11: Reserved
BIT12 ~ 13 Operation Command
Channel: 00-Panel/01-Terminal
/10-Reserved
BIT14 ~ 15 Bus Voltage Status: 00-Normal
/01-Low Voltage Protection/
10-Overpressure Protection
Operating state of
frequency converter
1
0
◆
d-18 0～65535h
Accumulation of inverter
operation Time (h)
1
0
d-19
2019～2039
Software Upgrade
Date (Year)
1
0
d-20
0～1231
Software Upgrade
Date(Month,Day)
1
0
d-21
—
Reservation
—
0
d-22
0～21
Type of third failure
1
0
d-23
0～21
Second Failure Type
1
0
d-24
0～21
Latest Failure Type
1
0
d-25
0.00～Upper limit frequency
Operating Frequency
at Current Failure
0.01Hz
0
d-26
0.0～6553.5A
Output Current at
Current Fault
0.1A
0
d-27
0～999V
Bus voltage at current
fault
1V
0
d-28
0.0℃～+110.0℃
Module temperature
at current faultC℃
0.1℃
0
d-29
Inverter status at current fault0~FFFFH
BIT0: Run/Shutdown
BIT1: Forward rotation/Reverse
BIT2: inching
BIT3: DC brake
BIT4: Reserved
BIT5: PassVoltage limit
BIT6: Constant speed frequency reduction
BIT7Overcurrent Limit
BIT8 ~ 9:00-Zero speed/01-Accelerate/
10-Deceleration/11-Uniform velocity
BIT10: Overload pre-alarm
BIT11: Reserved
BIT 12 ~ 13Run command channel:00-Panel/01-
Terminal/10-Reservation
BIT 14 ~ 15Bus voltage state:00-Normal/01-
Low voltage protection/10-Overpressure protection
normal/01-Low voltage protection
/10-Overpressure protection
Inverter status at
current fault
1
0
d-30
0.0～100.0（bar/Kg）
PIDPressure setting
0.1
0
d-31
0.0～100.0（bar/Kg）
PIDPressure feedback
0.1
0
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
