TM Series
Operating & Safety Instructions
English/USA – 01/10
Issue 06
1
Table of Contents
1 INTRODUCTION AND GENERAL INFORMATION PAGE
1.1 Foreword 2
1.2 Scope 3
1.3 Introducing the 120T Trailer Mount (TM) Series 3
1.4 General Specification 4
1.5 Identification 5-6
1.6 EC Declaration of Conformity 7
2 SAFETY
2.1 Mandatory Precautions 7-10
2.2 Environmental Limitations 11
2.3 Noise & Vibration 11
2.4 Test Report 11
3 PREPARATION AND INSPECTION
3.1 Unpacking 12
3.2 Preparation for Use 12
3.3 Pre-Operational Safety Check Schedules 13-14
3.4 Placard, Decals and Installation 15-20
3.5 Torque Requirements 21
4 OPERATION
4.1 Control Circuit Components 22
4.2 Setting Up Procedures 23
4.3 Ground Control Operation 24-25
4.4 Platform Control Operation 26-27
4.5 Cage Weigh System 28-30
4.6 Batteries and Charging 31-32
4.7 Transporting, Towing, Craneage, Storage and Setting to Work 33-36
4.8 Traction Drive 37-38
5 EMERGENCY CONTROLS
5.1 General 39
5.2 Emergency Procedures - Incapacitated Operator 39
5.3 Emergency Procedures - Machine Failure 39
5.4 Incident Notification 39
6 RESPONSIBILITIES
6.1 Changes in Ownership 40
6.2 Manual of Responsibilities (USA only) 40
6.3 Inspection/ Service Check List 41-42
