TM Series
Operating & Safety Instructions
USA – 06/11
Issue 01
16
3.5 TORQUE REQUIREMENTS
SCREW QUALITY/SIZE Tightening torque in ft lbs (Nm)
Grade 8.8 10.9
M 6 7.4 (10) 10 (14)
M 8 18.5 (25) 26 (35)
M 10 36 (49) 51 (69)
M 12 65 (86) 89 (120)
M 14 100 (135) 140 (190)
M 16 155 (210) 218 (295)
M 18 215 (290) 300 (405)
WHEEL NUTS 80ft lbs 110Nm
ROTATION GEAR RING BOLTS 155ft lbs 210Nm
