BOOM ROTATION
PASS
FAIL
N/A
Boom rotation assembly and motor are secure
Worm/wheel mesh correct, no excessive wear
No end float of worm in housing
Rotation gear wheel bolts secured
Rotation gear guards secure
BASKET
Operation of control valve and buttons
Operation of all booms over full range
Cylinders are silent
Basket levelling over full range
Boom rotation smooth over full range
Operation of boom 4 over full range (if fitted)
INTERNAL (POWER PACK)
Power pack and all components secure
All cables and terminals secure
All hose connections secure
Hoses not kinked or fouled
Charger/control box secure
Battery secure
Electrolyte level and specific gravity
Charger operation
Hydraulic oil level
FINISH
Operation of boom clamp
Pivot pin tag bolts
Correct decals, all visible
Canopy/bonnets
Grease nipples (Feet, Knuckle, Centre Post)
(Tow coupling, Rotation Gear, Boom 4-170)
LEAK CHECK
Cylinders (Lift, Outriggers, Telescope, Levelling)
Control valves
Check valves
Power pack/pump
Boom rotation motor
Hose connections
Comments, remedial work required etc:
INSPECTED BY: DATE: / /0
