Nikon 1 AW1 Quick Start Guide

until it clicks into place.
When you want to take off the non-waterproof 1 NIKKOR lens and go back to
using a waterproof 1 NIKKOR lens, turn the camera off, and press and hold the
lens release button while turning the lens. Then remove the O-ring protector and
clean any foreign matter from the O-ring, and attach the waterproof lens to the
AW1 camera.
You can also choose to put the camera’s body cap on the camera body, and not
attach a lens at this time. To do so, attach the body cap to the AW1 and place the
O-ring protector on the camera’s body cap.
For more detailed instructions, please consult the User’s Manual for the Nikon 1
AW1 waterproof camera.
TIPS:
1. Use a high capacity memory card and fully charged battery to get the
most use out of your Nikon 1 AW1 camera underwater. It is no fun to
begin seeing great subjects to photograph and finding the battery is
dead or the card full.
2. Before getting into the water, always double check that the battery
compartment door and media card slot door are securely shut.
3. When traveling, make sure you take along extra silicon grease and an
extra O-ring.
4. Replace the O-ring at least once a year, as preventative maintenance.
Use only the Nikon O-ring specifically designed for the Nikon 1 AW1
waterproof digital camera not for waterproof COOLPIX or Nikonos
cameras.

Nikon 1 AW1 Specifications

General

Sensor Type	CMOS
Effective Pixels	14.2 million
ISO Sensitivity	160-6400
Lens Mount	Nikon 1 mount
Autofocus System	Hybrid AF (phase-detection/contrast-detect AF)
Display Size	3.0 inches
Camera Type	Mirrorless
Screen Type	TFT LCD
Built-in Flash	Yes
GPS	No
Wi-Fi	No
Dimensions	113.3 x 71.5 x 37.5 mm
Sensor Size	13.2 x 8.8 mm
Continuous Shooting Speed	15 fps
Video Recording	1080/30p
Waterproof	Yes (15m)
Shockproof	Yes (2m)
Freezeproof	Yes (-10°C)
Battery Life	Approx. 220 shots
Image Stabilization	Lens-based
Shutter Speed	1/16000 to 30 s
LCD Screen	921, 000 dots
