Nikon 1 J1 Reference Manual

24
z
5
Shoot.
Smoothly press the shutter-release
button the rest of the way down to
release the shutter and record the
photograph. The access lamp will
light and the photograph will be dis-
played in the monitor for a few sec-
onds (the photo will automatically
clear from the display and the camera
will be ready to shoot when the shut-
ter-release button is pressed halfway).
Do not eject the memory card or remove
or disconnect the power source until the
lamp has gone out and recording is
complete.
Access lamp

Nikon 1 J1 Specifications

General

Sensor	CMOS
ISO Sensitivity	ISO 100-3200 (expandable to 6400)
Battery	EN-EL20 Rechargeable Li-ion Battery
Lens Mount	Nikon 1 mount
Dimensions	106 x 61 x 29.8 mm
Sensor Size	13.2 x 8.8 mm
Autofocus System	Hybrid autofocus (contrast-detect/phase-detect)
Continuous Shooting Speed	Up to 60 fps
LCD Screen	3.0-inch, 460, 000 dots
Video Recording	1080p Full HD at 30 fps
Storage Media	SD/SDHC/SDXC
Shutter Speed	1/16000 to 30 sec
