Nikon 1 S1 Reference Manual

134
i
Focus Lock
When Single AF is selected for Focus mode (0 128), focus lock
can be used to change the composition after focusing on the
subject in the center of the frame, allowing you to focus on a
subject that will not be in the center of the final composition. If
the camera is unable to focus using autofocus (0 130), you can
also focus on another subject at the same distance and then use
focus lock to recompose the photograph. Focus lock is most
effective when an option other than Auto-area is selected for
AF-area mode (0 133).
1
Lock focus.
Position the subject in the center of
the frame and press the shutter-
release button halfway to initiate
focus. Check that the focus area is dis-
played in green. Focus will remain
locked while the shutter-release but-
ton is pressed halfway.
2
Recompose the photograph and shoot.
Focus will remain locked between
shots.
Do not change the distance between the camera and the sub-
ject while focus lock is in effect. If the subject moves, lift your fin-
ger from the shutter-release button to end focus lock and then
focus again at the new distance.

Nikon 1 S1 Specifications

General

Camera type	Mirrorless
Sensor	CMOS
Effective Pixels	10.1 million
Lens Mount	Nikon 1 mount
Autofocus	Hybrid AF (Phase-detection/Contrast-detect AF)
LCD Screen Size	3.0 inches
LCD Screen Resolution	460, 000 dots
Storage Media	SD/SDHC/SDXC
Battery Life	Approx. 220 shots
Dimensions	102 x 60.5 x 29.7 mm
Sensor Size	13.2 mm x 8.8 mm
ISO Sensitivity	ISO 100-6400
Shutter Speed	1/16000 - 30 sec
Video Recording	Full HD 1080p
Battery	EN-EL20
Weight	240 g (including battery and memory card)
