29
s
Attaching a Grip
Follow the steps below to attach the grip.
1
Remove the grip connector cover.
Remove the grip connector cover
from the bottom of the camera and
place it in the holder. Be sure to
replace the cover when the grip is not
in use.
Connector cover holder
Mounting screw
Connector
cover holder
Mounting screw knob
Tripod socket
Fn3 button (0 12)
Shutter-release button
Connector cap
Signal contact
Sub-command
dial
