Specifications
Measurement system
Measurement range 5-500 m/6-550 yd.
Distance display (increment) Every 1 m/yd.
Optical system
Type Roof-prism monocular
Magnification (x) 6
Effective diameter of objective lens
(mm)
20
Angular field of view (real) (˚) 6.0
Eye relief (mm) 16.7
Exit pupil (mm) 3.3
Diopter adjustment ±4m
-
1
Others
Operating temperature (˚C) -10 — +50
Power source CR2 lithium battery x 1 (DC 3V)
Dimensions (L x H x W) (mm) 91 x 73 x 37
Weight (g) Approx. 125 (without battery)
Structure
JIS/IEC protection class 4 (IPX4) equivalent (under
our testing condtions)
Safety
Class 1M Laser Product (EN/IEC60825-1:2007)
Class I Laser Product (FDA/21 CFR Part 1040.10:1985)
EMC
FCC Part15 SubPartB class B, EU:EMC directive, AS/
NZS, VCCI classB
Environment RoHS, WEEE
