GND ( - )

󳂉 󳊛 󲩆󲩝󲩯 󲩬󲩧󲩧󲩤󳊛 󲩆󲩝󲩯 󲩬󲩧󲩧󲩤󲩆󲩝󲩯󲨘󲩬󲩧󲩧󲩤

How to create self-made tool

GMR-output inspecting tool

By converting a repair part of the main PCB (1S020-552), create a self-made tool that is used for the

inspection and adjustment of GMR encoder output waveform.

Solder the wire each to the four locations of the pattern on the main PCB.

Constant voltage

power supply ( + )

Oscilloscope (2ch

）

Oscilloscope (1ch

）
