Laser Rangefinders
Forestry 550
Ideal for basic forestry and land surveys — display in metres, yards or feet
• Inadditiontoactualdistancemeasurement,height,verticalseparation(differenceinheightbetweentwotargets),horizontaldistanceandanglecanbe
easily measured.
• TheresultsaredisplayedonbothinternalandexternalLCDpanels.Theexternalpaneldisplaysallresultssimultaneously.
• Twomeasurementmodes(TargetPrioritySwitchSystem)areavailable:
First Target Priority Mode displays the range to the nearest target taken from multiple results obtained with a single measurement.
Distant Target Priority Mode displays the range to the farthest target taken from multiple results obtained with a single measurement — especially
useful for forestry and hunting.
• Displayinfeetaswellasmetresandyardsisavailablewiththismodel.
• Measurementrange:10-500m /11-550yd./33-999ft.
(See page 34 for features common to Nikon Laser Rangefinders)
Forestry 550
Internal display External display
Hgt and Hgt2 are solid.
When the measurement is successful, you see the height from the base to the top displayed
ontheinternalLCDwithHgt+Hgt2(solid).
For more information, refer to the external LCD.
“Base” and “top” can be switched.
The specifications of the product may not be achieved depending on the target object’s shape, surface texture
and nature, and/or weather conditions.
Note: The origin of the technique of this Laser Rangefinder with inclinometer is the Surveying Instruments incorporated measuring capability of both
distance and angle which were developed by Nikon Corporation. Among such products, especially, the first highly advanced electronic model, the Total
Station DTM-1, is the root (Sold in 1985).
Model name Forestry 550
Distance:10-500m/11-550 yd./33-999 ft. (*999 ft.: 304.5m/333 yd.)
Angle:
±
89°
[Internal Display]
Act (Actual Distance):
every 0.5m/yd., 1.0 ft. (shorter than 100m/yd./ft.)
every 1.0m/yd., 1.0 ft. (greater than 100m/yd./ft.)
Hor (Horizontal Distance) and Hgt (Height):
every 0.2m/yd., 0.5 ft. (shorter than 100m/yd./ft.)
every 1.0m/yd., 1.0 ft. (greater than 100m/yd./ft.)
Ang (Angle):
every 0.1° (less than 10°)
every 1.0° (more than 10°)
*Downward angle from the horizontal line: with display “-“
[External Display]
Act (Actual Distance): every 0.5m/yd., 1.0 ft.
Hor (Horizontal Distance) and Hgt (Height): every 0.2m/yd., 0.5 ft.
Ang (Angle): every 0.1°
6x
21mm
6.0°
3.5mm
18.2mm
130x69x45mm
210g (excluding battery)
CR2 lithium battery x 1 (DC 3V)
Auto power shutoff function equipped (after about 30 sec.)
Class 1M Laser product (EN/IEC60825-1:2007)
FCC Part15 SubPartB class B, CE:EMC directive, C-tick, VCCI
class B
RoHS, WEEE
Measurement range
Distance display
(Increment)
Magnification
Effective objective
diameter
Actual field of view
Exit pupil
Eye relief
Dimensions (LxHxW)
Weight
Power source
Safety
EMC
Environment
External display
1. Measurement unit (m /yd./ft.)
2. Height
3. Actual (linear) Distance
4. Horizontal Distance
5. Angle (°)
Internal display
1. Actual (linear) Distance
2. Horizontal Distance
3. Height
4. Angle
5. Height between two points
6. First Target Priority mode
7. Distant Target Priority mode
8. Battery condition
9. Distance
10. Unit of measure (m/yd.)
(No unit displayed for ft.)
11. Target mark ( )
12. Laser irradiation ( )
Measurement example (2-point height measurement)
Finder
Top (Hgt2)
Base (Hgt)
