Connecting the WT-5
q Open the camera’s
peripheral connector
cover and rotate it up
out of the way.
w Fully insert the WT-5
connector into the
camera peripheral
connector.
e Rotate the locking
wheel to lock the
WT-5 in place.
D Power Source
The WT-5 is not equipped with a battery or power switch. Power is
supplied from the camera.
A Connection Status
Connection status is shown by the LED on the
WT-5.
LED
LED Status
K
(glows green)
Connected.
H
(flashes green)
Ready to connect.
H
(flashes yellow)
Error.
