Overview of temperature sensors
T10
T2T5
T6
RH
T1
T2
T10
T1: Outdoor air sensor
T2/T7: Supply air sensor
T5: Condenser sensor
T6: Evaporator sensor
T9: Water after-heating element
T10:Extract air sensor (room temperature)
8
