INSTALLATION (CONT’D)

Using a New Construction Bracket:

(See Figure 12 on page 17.)

1. Connect a properly configured CAT-5 cable to the T568A system terminal

on the back of the keypad.

2. Install keypad to Display Keypad Mounting Bracket (IntelliControl ICS

Part #FG01192; not included) as shown.

3. Finish with appropriate color trim plate.

See “Accessories” in this guide for color options and part numbers.
