12
I
NFRARED
M
AIN
S
YSTEM
U
NIT
Power Status — Introduction
To properly wire an Intellipad to the MSU140, refer to
Figure 5.
By providing 3-30V AC/DC to the status input jack of your
MSU140 you can send a status signal to sensors or an
IntelliPad without running any additional wiring. Built
into the MSU140 is a Niles status signal generator. When
the MSU140 sees 3-30V AC/DC at the status jack it broad-
casts a status signal over your existing IR sensor wires. Any
sensor or IntelliPad connected to one of your sensor wires
will display the power status of your system.
