Niles RCA3 User Manual

12
R EMOTE C ONTROL A NYWHERE ! K IT
Step 7 – Reconnecting the Connection Hub
Reconnect the sensor plug, flashers and power supply as
outlined in steps 2, 3 and 4 (
Figure 10).
That’s it! Now you are ready to control your audio/video
equipment from the room you chose.
NOTE
Make sure that the
stripped ends of the
wire do not come
in contact with
one another or any
surface other than
the connector.
Additional
Flashers
REMOTE CONTROL ANYWHERE!
CONNECTION HUB
3-30V
AC/DC
STATUS
IN
Figure 10: Connecting
Power Supply and
Flashers
DS00408ACN_RCA3 Kit.qxp 1/17/05 3:52 PM Page 12
