Steps 11-6 attenuate -3 dB per step; steps 5-2 are -6 dB
per step. Step 12 is “full-on” and step 1 is “full-off”.
● Greater dynamic range—you get 42 dB of total attenua-
tion instead of the typical 20 or 30 dB.
● POP-FREE switching between all steps.
● 100% tested, electronically and acoustically, for frequency
response, distortion and power handling.
● The connectors on the VCS-2D are removable and
accommodate up to 14 gauge speaker wire. The
connectors simplify your installation:
• The speaker wires are easier to attach—no heavy
control to hold onto.
• The control may be removed without disconnecting
any wiring.
• ”Wire-Guard” barriers between each connector
terminal reduce the chance of a short-circuit.
● Mounting depth of only 2 9/16”. Fits into standard 18cu.in.
1-gang electrical boxes.
● Printed circuit board construction uses no hand wiring,
assuring high reliability.
2
PP
RR EE MM II UU MM
SS
TT EE RR EE OO
VV
OO LL UU MM EE
CC
OO NN TT RR OO LL
DS00101C/VCS-2D 2/5/99 1:32 PM Page 4
