Niles VCS-2D User Manual

Introduction
The VCS-2D is a wall-mount, Decora
®
style speaker volume
control. It connects between the speaker-level output of an
amplifier, speaker selector, etc. and a pair of speakers.
A perfect application for the VCS-2D is adjusting the volume
of remotely located speakers.The VCS-2D adjusts the volume
of speakers connected to it by attenuating the amplifier signal.
Niles volume controls use autoformers instead of L-pads for the
volume controlling element. This assures minimal internal
power dissipation with virtually no power wasted as heat.
Features and Benefits
The VCS-2D offers a number of improvements over other
volume controls.
● Interchangeable Decora-style inserts for fast, easy color
change. Inserts and knobs (sold separately) are available
in a variety of colors.
● The VCS-2D uses a 12 position control, which is superior
to 10 position designs. You get a broader range of adjust-
ment—there are 10 steps of attenuation instead of 8.
TABLE OF CONTENTS
Introduction 1
Features and
Benefits 1
Installation
Considerations 3
Installation 8
Operation 10
Specifications 10
PP
RR EE MM II UU MM
SS
TT EE RR EE OO
VV
OO LL UU MM EE
CC
OO NN TT RR OO LL
VCS-2D
Premium Stereo
Volume Control
1
DS00101C/VCS-2D 2/5/99 1:32 PM Page 1
