Niles VCS-2D User Manual

● Isolated left and right channel grounds make it safe for
use with any amplifier.
● May be used with 4, 6, or 8 ohm speaker systems.
● Ideal for both home and commercial sound installations.
● Only screwdriver and wire stripper required for installation.
● Power handling: 60 watts/channel peak music power.
● Frequency response: 20 Hz to 20 kHz ±1.2 dB.
● Available colors: White, Bone, Almond, or Black.
● Ten year parts and labor warranty.
● Proudly made in the USA.
Installation Considerations
The VCS-2D is a Decora-style module and is designed to
use standard Decora-style faceplates and mounting
hardware. Decora faceplates (up to 6-gang) with color-
matched plate screws are available from your Niles dealer.
P-Rings and Electrical Boxes
The mounting depth of the VCS-2D is 2
9/16”. When
installed, the unit extends 2
1/16” behind the sheetrock wall
(assuming
1/2” sheetrock). For installation, you must choose
between a standard light switch plaster ring (p-ring) or a
standard 18 cu. in. (or larger) electrical box. Suitable p-rings
3
PP
RR EE MM II UU MM
SS
TT EE RR EE OO
VV
OO LL UU MM EE
CC
OO NN TT RR OO LL
*
Only required if changing color of unit.
TOOLS REQUIRED
• No. 2 Phillips
Screwdriver
• 1/8" Standard
Slotted Screwdriver
• 1/4" Standard
Slotted Screwdriver
• Wire Stripper
• 5/64" Allen Wrench
*
DS00101C/VCS-2D 2/5/99 1:32 PM Page 5
