3 Before you start using your high pressure washer
See the pictorial quick reference guide – unpacking.
Illustration shows the operation elements and how to prepare your machine for use.
Operation elements
1. Start/stop switch
2. Water inlet with fi lter
3. High pressure connection (models without hose reel)
4. High pressure hose
5. Electric cable
6. Click&Clean spray lance
7. Spray handle with lock (7a)
8. Click&Clean Tornado PR nozzle
9. Click&Clean Powerspeed nozzle
10. Foam sprayer
11. Nozzle cleaning tool
12. Hose reel (not standard)
13. Model tag
14. Trolley handle (telescopic handle)
15. Hose hook
16. Hexagon key for handle and bracket mounting
17. Button for telescopic handle
18. Turnable cable hook
19. Quick coupling
3.1 Mounting of trolley handle, hose hook and hose reel
Mounting of trolley handle and hose hook (standard models)
A1 Push down the trolley handle (14) over the two metal tubes. Make sure that the handle
is mounted as illustrated. Mount screws with nuts (make sure that the screws go through
handle as well as tube).
A2 Mount the hose hook (15) on the handle (2 screws).
Mounting of hose reel handle (models with hose reel)
A3 Click the hose reel handle on to the trolley handle (no screws).
3.2 Mounting of quick coupling
A4 When mounting the quick coupling for the fi rst time, check that the factory fi tted fi lter is
positioned in the water inlet pipe.
A5 Screw the quick coupling tight on to the water inlet (2).
IMPORTANT!
The inlet fi lter must always be fi tted in the water inlet pipe to fi lter out sand, lime stone and other
impurities as these will damage the pump valves. The fi lter is factory fi tted.
If the fi lter is removed this will invalidate the guarantee.
3.3 Telescopic handle
A6 The machine features a tele scopic handle. To raise or lower the handle, press the button
(17) and move the handle upwards or downwards. When a click is heard, the handle is in
right position.
