12
Original Instructions
4.4 Mounting of quick
coupling
1. Screw the quick coupling
tight on to the water inlet (2).
Note: The inlet filter must al-
ways be fitted in the water inlet
pipe to filter out major impuri-
ties as these will damage the
pump valves.
Caution: Failure
to fit the filter will
invalidate the
guarantee.
4.5 Mounting of high
pressure hose
Attach the high pressure hose
(4) to the spray handle (7).
5 Operating your pressure washer
5.1 Connection of high pres-
sure hose
Machines without hose reel: At-
tach the high pressure hose (4)
to the high pressure connection
of the machine (3).
Only max. 7 m additional exten-
sion hose can be added.
Machines with hose reel: Un-
wind the high pressure hose
completely.
