TECHNICAL SPECIFICATIONS (AS INSTALLED AND TESTED ON THE UNIT)
Model SC6000 910C SC6000 860D SC6000 1050D
Model
No.
56116003 56116005
56116013
56116004
56116012
Voltage, Batteries V 36V 36V 36V
Battery Capacity (max) Ah C5 320 320 320
Protection Grade, Operating Class 3 Class 3 Class 3
Protection Grade, Charging
Class 1 Class 1 Class 1
Sound Pressure Level
IEC 60335-2-72: 2002 Amend. 1:2005, ISO
11203, ISO 3744
dB(A)/20Pa 69 69 69
Sound Pressure level - KpA
(IEC 60335-2-72, ISO 11203) Uncertainty
dB(A) 3.0 3.0 3.0
Gross Vehicle Weight* lbs / kg 2359 / 1070 2359 / 1070 2359 / 1070
Transportation Weight**
lbs / kg 1784 / 810 1784 / 810 1784 / 810
Maximum Wheel Floor Loading (center front) psi / kg/cm
2
120 / 8.43 104 / 7.31 120 / 8.43
Maximum Wheel Floor Loading (right rear) psi / kg/cm
2
128 / 8.99 121 / 8.50 128 / 8.99
Maximum Wheel Floor Loading (left rear) psi / kg/cm
2
110 / 7.73 109 / 7.66 110 / 7.73
Vibrations at the Hand Controls (ISO 5349-1) m/s
2
<2.5 <2.5 <2.5
Vibrations at the Seat (EN 1032)
m/s
2
<0.04 <0.02 <0.02
Gradeability Transport with Weight Kit 20.9% (11.8°) 20.9% (11.8°) 20.9% (11.8°)
Gradeability Transport without Weight Kit 18.5% (10.5°) 18.5% (10.5°) 18.5% (10.5°)
Gradeability Cleaning with Weight Kit 16.9% (9.6°) 16.9% (9.6°) 16.9% (9.6°)
Gradeability Cleaning without Weight Kit 12.2% (7°) 12.2% (7°) 12.2% (7°)
Machine Length inch / cm 70 / 178
Machine Height inch / cm 62.3 / 158
Machine Height (w/overhead guard) inch / cm 82 / 208
Machine Height (w/short overhead guard) inch / cm 79 / 200
Machine Width inch / cm 46 / 117 39 / 99 46 / 117
Machine Width with Squeegee inch / cm 48.5 / 123 “K” 43 / 109 “J” 48.5 / 123 “K”
Minimum Aisle Turn Width inch / cm 79.5 / 202
Solution Tank Capacity Gallon / L 50 / 190
Recovery Tank Capacity Gallon / L 50 / 190
Transport Speed (Fwd. Maximum) mph / kph 5.6 / 9.0
Transport Speed (Rev. Maximum) mph / kph 2.6 / 4.2
Battery Compartment Size (approximate)
Height (maximum) inch / cm 17.25 /43.8
Width (maximum) inch / cm 22 / 55.9
Length (maximum) inch / cm 24 / 61
Scrub brush size
Outside Scrub Brush Diameter - Cylindrical
(inside core is 3.5 in / 8.9 cm)
inch / cm 7.1 / 18 — —
Scrub Brush Length - Cylindrical
(two brushes per machine)
inch / cm 35.58 / 90.4 — —
Brush Diameter - Disc
inch / cm
— (Quantity of 2) at 17 / 43 (Quantity of 2) at 20 / 51
Scrub Brush
Speed
Cylindrical RPM 760 — —
Disc RPM — 250 250
Hopper Capacity - Cylindrical in
3
/ L 744 / 12.2 — —
Cleaning Path Width (scrubbing path) inch / cm 36 / 91.4 34 / 86.3 40 / 101.6
Sweeping Path with optional side broom -
Cylindrical
inch / cm 43 / 109 — —
*Gross Vehicle Weight: Standard machine without options, full solution tank and empty recovery tank, with removable scrub brushes, batteries installed and 75 kg
operator.
**Transportation Weight: Standard machine without options, empty solution and recovery tanks, with batteries installed and no operator.
revised 9/2016
4/2016 A - 35 56091168 - SC6000
