ELECTRICAL SYSTEM
ENGLISH
SERVICE MANUAL
42
1463162000(2)2009-02 SW 750
HOOD SAFETY SWITCH OPERATION CHECK
Remove the hood (30) (see the procedure in the relevant paragraph).1.
When the hood (30) is removed, press the main switch (1) and check that all machine functions are disabled.2.
If necessary, check the microswitch (A) operation and, if necessary, replace it.
S301613
LAMELLAR FUSE CHECK/REPLACEMENT
Remove the hood (30) (see the procedure in the relevant paragraph).1.
Check/replace the 7.5 A vacuum system motor lamellar fuse (A).2.
Install the hood (30) (see the procedure in the relevant paragraph).3.
S301614
