T22 Plus - T40 Plus - T40W Plus
01/2015
7
C380
GB
Technical specications
Parameter Units T22 Plus T40 Plus T40W Plus
Dust classes L - M - H
Voltage (50 Hz) V 400 400 400
Power rating (T_Plus / T_Plus Z22) kW 2.2 4.3 4
Power rating (EN 60335-2-69) (50 Hz) (T_Plus / T_Plus Z22) kW 2.1 2.7 3.4
Power rating (T_Plus Z2 / T_Plus Z21) kW 4 7.5 7.5
Power rating (EN 60335-2-69) (50 Hz) (T_Plus Z2 / T_Plus Z21) kW - - -
Noise level (Lpf) (EN60335-2-69) dB(A) 67 71 71
Protection IP 55 / 65(
**
) 55 / 65(
**
) 55 / 65(
**
)
Electrical protection (Insulation) Class I I I
Insulation class of motor Class F F F
Container capacity L 100 50 100 50 100 50
Inlet (diameter) mm 70 70 70
Max vacuum with limiting valve (T_Plus / T_Plus Z22) hPa - mbar 210 360 190
Max vacuum with limiting valve (T_Plus Z2 / T_Plus Z21) hPa - mbar 260 350 230
Maximum air ow rate(without hose and reductions) m
3
/h - L/min’ 315 - 5250 315 - 5250 489 - 8150
Maximum air ow rate (with hose, length: 3 m, diameter: 50 mm) m
3
/h - L/min’ 270 - 4500 270 - 4500 420 - 7000
Hoses allowed for “L” and “standard” classes (diameter) mm 70(*)/50 70(*)/50 70(*)/50
Hoses allowed for “M” and “H” classes (diameter) mm 50 50 70/50
Main lter surface for “standard”, “L” and “M” classes m
2
1.95 1.95 3.5
Cartridge lter surface m
2
5.25 5.25 5.25
Upstream absolute “H” lter surface m
2
3.5 3.5 3.5
Absolute lter efciency (EN 1822) % 99.995 (H14) 99.995 (H14) 99.995 (H14)
Downstream “ULPA 15” absolute lter surface m
2
8 8 8
(*) Only for non-ATEX use
(**) T__ Plus Z21
Dimensions
Figure 4
Model
T22 Plus T40 Plus T40W Plus
100L 50L 100L 50L 100L 50L
A (mm) 1290 1290 1290 1290 1290 1290
B (mm) 600 600 600 600 600 600
C (mm) 1540 1260 1540 1260 1640 1360
■ Storage conditions:
T : -10°C ÷ +40°C
Humidity: 85%
■ Operating conditions:
Maximum altitude: 800 m
(Up to 2,000 m with reduced performances)
T : -10°C ÷ +40°C
Humidity: 85%
