(8) to the absolute lter holder disc (7).
■ Insert the cover (3) again.
■ Close the cover hermetically by means of the lever (4) and
lock the safety bolt (5) again.
■ Fit the vacuum hose (12) back in place and tighten the
calmp (13).
[ NOTE ]
If the vacuum cleaner is ATEX variant: perform galvanic
continuity tests as shown in the relevant manual.
Standard EN 60335-2-69 prescribes inspections at regular
intervals or after repairs or modications.
Motor cooling fan inspection and cleaning
WARNING!
These operations can only be carried out by trained
and qualied personnel.
Periodically clean the motor cooling fan to prevent the motor
from overheating, especially if the vacuum cleaner is used in
a dusty place. (See Fig. 5)
Tightness inspection
Hoses check
Make sure that connecting hoses are in a good condition and
correctly xed.
If the hoses are damaged, broken or badly connected to the
unions, they must be replaced.
When sticky materials are treated, check for possible clogging
along the hose (3, Fig. 17), in the inlet and on the bafe plate
inside the ltering chamber.
Scrape inlet (3, Fig. 17) from the outside and remove the
deposited waste as indicated in gure 17.
Filtering chamber tightness check
If the gasket (1, Fig. 18) between the container and the
ltering chamber (3) fails to guarantee tightness:
■ Loosen the four screws (2) that lock the ltering chamber
(3) against the vacuum cleaner structure.
■ Allow the ltering chamber (3) to lower down and tighten the
screws (2) once it has reached the tightness position.
If an optimal seal cannot be obtained and the gasket (1) is
torn or cracked, etc. it must be replaced.
Separator cleaning and replacement
(optional)
[ NOTE ]
If there is only a dust deposit on the separator (3, Fig. 19)
allow the dust to drop through the central hole.
The separator (3, Fig. 19) should rst be disassembled in
order to be perfectly cleaned:
■ Use the lever (1) to remove the cover (2) together with
the primary lter.
■ Unscrew the two screws (4) and remove it from the
container.
Replace the part if it is excessively worn.
Assemble the components in the reverse order of
disassembly.
Device disposal
Figure 20
Dispose of the device in compliance with the laws in force.
■ Proper disposal (electric and electronic waste).
(Applicable in the European Union and in countries
providing a separate collection system)
The above symbol (Fig. 20), which is present on the product
or in its documentation, indicates that the product cannot be
disposed of together with other domestic waste at the end of
its life cycle.
To prevent damage to the environment or health caused by
improper waste disposal, please separate this product from
other waste and recycle it responsibly in order to support the
sustainable reutilisation of material resources.
This product can not be disposed of together with other
commercial waste.
