T22 Plus - T40 Plus - T40W Plus
01/2015
13
C380
E
3. Electroválvula 2 para la limpieza del ltro
4. Electroválvula 3 para la limpieza del ltro
5. Electroválvula 4 para la limpieza del ltro
(predisposición)
T1 = Tiempo de limpieza del ltro
T2 = Tiempo de espera
T3 = Tiempo entre los ciclos de limpieza
Aspiradora de clase L, M, H con agitador eléctrico
de ltro o sensor de retención materiales sólidos
Figura 29
1. Entrada de corriente
2. Relé secuencia fase
3. Aspirador
4. Agitador eléctrico del ltro
Figura 30
1. Transformador
2. Indicador de tensión
3. Luz blanca
Figura 31
1. Control de nivel
2. Botón de parada
3. Botón de inicio
4. Contactor del eje motor
5. Indicación secuencia fase
6. Contactor del agitador del ltro
7. Botón del agitador del ltro
8. Luz amarilla
Figura 32
1. Caja de fusibles
2. Control de nivel
Figura 33
Ele-
mento
Tipo Descripción
Canti-
dad
H1 40000563 Kit del indicador blanco 1
H3 40000564 Kit del indicador amarillo 1
KM1
Z8 39281
Z8 39731
Contactor kW4 24 VAC 1NO 1
KM2 Z8 391006 Contactor kW3 24 VAC 1NC 1
PA 40000565 Kit del botón de parada (rojo) 1
PM 40000562 Kit del botón de arranque (verde) 1
PS1 40000598 Kit del botón amarillo 1
Q1
Z8 39915 Disyuntor 5,5-8 A 1
Z8 39916 Disyuntor 9-12,5 A 1
Q2 Z8 39746 Disyuntor 0,7-1 A S00 1
SF1 Z8 391120 Relé de sucesión de fase de 400 V 1
TR1 Z8 391050 Transformador 20 VA 400/24 V 1
