26
1)
Options / model variants
Original instructions
POSEIDON 5-6-7
9.4 Technical Data
POSEIDON
5-41 PA
5-41 PAXT
5-53 PA
5-53 PAXT
5-56 FA 5-56 PA
Country variant EU EU EU EU EU EU
Possible voltage, V/ph/Frez. V/ph/Hz 400V/3ph/50Hz 400V/3ph/50Hz 400V/3ph/50Hz 400V/3ph/50Hz 400V/3ph/50Hz 400V/3ph/50Hz
Fuse
A161616161616
Power rating kW 4,8 4,8 6,1 6,1 6,1 6,1
Working pressure p
IEC
bar (MPa) 180 (18) 180 (18) 200 (20) 200 (20) 200 (20) 200 (20)
Water flow Q
IEC
l/h 760 760 940 940 960 960
Max. water pressure p
max
bar (MPa) 250 (25) 250 (25) 250 (25) 250 (25) 250 (25) 250 (25)
Water flow Q
max
l/h 840 840 1000 1050 1050 1050
Max. water inlet temperature
Intake-Pressure operation
°C (°F) 60 (140) 60 (140) 60 (140) 60 (140) 60 (140) 60 (140)
Max. water inlet pressure bar (MPa) 10 (1) 10 (1) 10 (1) 10 (1) 10 (1) 10 (1)
Max. dry suction height m 1 1 1 1 1 1
Dimensions, l x w x h mm 735x570x1020 890x570x1020 735x570x1020 890x570x1020 735x570x1020 735x570x1020
Weight of cleaner kg 66 72 71 76 73 73
Sound pressure level L
PA
at a
distance of 1 m
dB(A) 75 75 76 76 76 76
Guarantied sound power level
L
WA
dB(A) 88 88 89 89 89 89
Vibration ISO 5349 m/s² <1,5 +/- 1 <1,5 +/- 1 <1,5 +/- 1 <1,5 +/- 1 <1,5 +/- 1 <1,5 +/- 1
Recoil forces, lance1 / lance 2 N 34,4 / 36 34,9 / 36,5 44,7 / 46,7 45,4 / 47,4 46 / 46,7 46 / 46,7
Oil quantity l 0,73 0,73 0,73 0,73 0,73 0,73
Oil type
BP Energol
GR-XP220
BP Energol
GR-XP220
BP Energol
GR-XP220
BP Energol
GR-XP220
BP Energol
GR-XP220
BP Energol
GR-XP220
Specifications and details are subject to change without prior notice.
