SC100 - SCRUBTEC 130

Service Manual

Nilsk SC100, 107408100 - 107408102 - 107408103

Nilsk Alto Scrubtec 130, 107408140 - 107408150 - 107408152

English

04/2015 (1) Form No. 107415442

Table of Contents

Default Chapter2
- Table of Contents2
General Information3
Electrical System12
- General Wiring Diagram12
- Removal and Installation14
Solution System29
- Maintenance and Adjustments29
  - Cylindrical Brush, Brush Compartment and Dosing Bridge Cleaning29
  - Solution Filter Cleaning29
- Removal and Installation30
Cylindrical Brush System38
- Removal and Installation38
  - Belt and Pulley Disassembly/Assembly38

Questions and Answers:

C
Christopher HowellAug 8, 2025
Why is the dirty water vacuuming insufficient in my Nilfisk-ALTO Scrubber?
- T
  Tanner LaneAug 8, 2025
  Insufficient dirty water vacuuming in your Nilfisk-ALTO Scrubber can be caused by a few things. The recovery tank might be full and needs emptying. The squeegee bars could be dirty, or the blades might be worn or damaged, so you should clean and check them. Also, the inspection compartment could be dirty and require cleaning. Check if the vacuum hose is disconnected or dirty, and connect or clean it. Finally, the air filter might be dirty and need cleaning.
P
perezanitaAug 18, 2025
How to fix insufficient solution flow to the brush of my Nilfisk-ALTO Scrubber?
- K
  krausemaryAug 18, 2025
  If the solution flow to the brush of your Nilfisk-ALTO Scrubber is insufficient, consider these potential causes: the solution filter might be dirty and needs cleaning, the dosing bridge could be clogged and require cleaning, or the solenoid valve may be broken and needs replacement.
M
Michael BakerAug 27, 2025
What to do if squeegees leave marks on the floor when using my Nilfisk-ALTO Scrubber?
- C
  cjohnsonAug 27, 2025
  If the squeegees are leaving marks on the floor while using your Nilfisk-ALTO Scrubber, it might be due to debris under the squeegee blades, which needs to be removed. Alternatively, the squeegee blades might be worn, chipped, or torn, requiring replacement.

Nilfisk-ALTO SCRUBTEC 130 Specifications

General

Model	SCRUBTEC 130
Weight	54 kg
Power Source	Battery
Voltage	12 V
Battery voltage	12 V
Type	Scrubber

Summary

General Information

Machine General Description

Describes the SC100 and Scrubtec 130 commercial cleaning machines.

Service Manual Purpose and Field of Application

Technical resource for service technicians for maintenance and repair.

Service and Spare Parts

Specifies authorized personnel for service and ordering parts.

Safety

Highlights potentially dangerous situations and necessary precautions for operator safety.

General Instructions

Provides specific warnings and cautions for machine operation and safety.

Technical Data

Maintenance

Scheduled Maintenance Table

Provides a chart for scheduled maintenance procedures and frequencies.

Troubleshooting

Electrical System

General Wiring Diagram

Illustrates the electrical wiring for SC100 and Scrubtec 130 models.

Function Board Connections

Details the connections on the function electronic board.

Motor Disassembly/Assembly

Function Electronic Board Disassembly/Assembly

Switch Panel Disassembly/Assembly

Parking Position Microswitch Disassembly/Assembly

Solution System

Maintenance and Adjustments

Cylindrical brush, brush compartment and dosing bridge cleaning

Disassembly/assembly of the solution level sensor (inside the tank)

Disassembly/assembly of the sensor receiving the solution level

Dosing pump Disassembly/Assembly

Cylindrical Brush System

Removal and Installation

Belt and Pulley Disassembly/Assembly
