C391
10
09/2014
VHW310 - VHW311
GB
Motor cooling fan inspection and cleaning
Periodically clean the motor cooling fan to prevent the motor
from overheating, especially if the device is used in a dusty
place.
Tightness inspection
Figure 12
1. Blower connecting hose
2. Vacuum hose
Hoses check
Make sure that connecting hose (1) is in a good condition and
correctly xed.
If the hose is damaged, broken or badly connected to the
unions, it must be replaced.
When sticky materials are treated, check for possible clogging
along the hose (2), in the inlet and on the bafe plate inside
the container.
Scrape the inlet from the outside and remove the deposited
waste as indicated in the gure.
Disposing of the vacuum cleaner
Figure 13
Dispose of the vacuum cleaner in compliance with the laws in
force.
■ Proper disposal (electric and electronic waste).
(Applicable in the European Union and in countries
providing a separate collection system)
The above symbol (Fig. 13), which is present on the product
or in its documentation, indicates that the product cannot be
disposed of together with other domestic waste at the end of
its life cycle.
To prevent damage to the environment or health caused by
improper waste disposal, please separate this product from
other waste and recycle it responsibly in order to support the
sustainable reutilisation of material resources.
This product can not be disposed of together with other
commercial waste.
Wiring diagrams
Basic model
Figure 16
1. Plug
2. Vacuum cleaner
3. Circuit breaker
Item Part
Code
VHW310
(if equipped)
VHW311T
Q1
Circuit breaker Z8 39319 Z8 39319
Box for Q1 Z8 39932 Z8 39932
