VHW320 - VHW321 - VHW420 - VHW421 - VHW440
09/2014
15
C393
GB
Filtering chamber tightness check
Figure 21
If the gasket (2) between the container (3) and the ltering
chamber (1) is torn, broken, etc. replace the gasket (2).
Vacuum cleaner disposal
Figure 22
Dispose of the device in compliance with the laws in force.
■ Proper disposal (electric and electronic waste).
(Applicable in the European Union and in countries
providing a separate collection system)
The above symbol (Fig. 22), which is present on the product
or in its documentation, indicates that the product cannot be
disposed of together with other domestic waste at the end of
its life cycle.
To prevent damage to the environment or health caused by
improper waste disposal, please separate this product from
other waste and recycle it responsibly in order to support the
sustainable reutilisation of material resources.
This product can not be disposed of together with other
commercial waste.
Wiring diagrams
Basic model
Figure 24
1. Plug
2. Vacuuming unit
3. Circuit breaker
Item Part
Code
VHW320 VHW321
Q1
Circuit breaker 4083901536
Box for Q1 Z8 39932 Z8 39969
Item Part
Code
VHW420 VHW421 VHW440
Q1
Circuit breaker 4083901538 4083901540
Box for Q1 Z8 39332 Z8 39969 Z8 39932
InniClean Model
Figure 25
1. Plug
2. Vacuuming unit
3. Circuit breaker
4. Timer
Item Part
Code
VHW320IC
VHW420IC
VHW440 IC
Q1
Circuit
breaker
Z8 39679 +
Z8 39687
Z8 39680 +
Z8 39687
Box for Q1 Z8 39932
A1 Timer
4083901505
TR1
Transformer Z58 39702
Model with cartridge kit
Figure 26
1. Plug
2. Vacuuming unit
3. Circuit breaker
4. Timer
Item Part
Code
VHW420C VHW440C
Q1
Circuit breaker
Z8 39679 +
Z8 39687
Z8 39680 +
Z8 39687
Box for Q1 Z8 391165
A1 Timer 4083901616
TS2 Transformer Z8 391050
Atex Z21 - Z2 Model
Figure 24
1. Plug
2. Vacuuming unit
3. Circuit breaker
Item Part
Code
VHW321 VHW421
Q1
Circuit breaker 4083901537 4083901539
Box for Q1 4083901587
