6
42445 Avenida Alvarado, Temecula, CA 92590
(800) 451-9343, www.nimbuswater.com
CS-2 Push Handle Faucet
For easier installa on, a ach all tubing prior to moun ng the
faucet.
1. Insert polished faucet base onto base of faucet.
2. Push the 1/4” drain tubing onto the 1/4” barb fi ng. This tube
must be of suffi cient length to reach the white swivel with yellow
collet on the membrane desalinator.
3. Push the 3/8” tubing onto the larger 3/8” barbed fi ng, being
sure you have enough tubing to reach the drain saddle.
4. Slip the 1/4" and 3/8" tubing though opening in polished faucet
base. Slide white plas c spacer open-end-up onto the threaded
faucet stem (2).
5. Thread the 3/8" washer (3) and moun ng lock nut (4) onto the
threaded stem. (Fig 6)
6. Thread faucet quick-connect adapter (5) on to threads of faucet
stem. NOTE: This connec on should be hand- ghtened only. Push
one end of product tubing into connec on.
7. Insert tubing and faucet assembly down through the sink hole.
8. Posi on the faucet to the desired handle orienta on. Slip the
slo ed washer (1) between the white plas c spacer and the sink.
Securely hand ghten the moun ng nut.
9. Connect the 3/8” tubing to the drain saddle assembly using the
drain connector nut supplied. This tubing should follow as direct a
path as possible; long runs, looping or deep sags will restrict nor-
mal brine fl ow to the drain. Save the unused por on of the tubing
for the installa on of the storage tank.
10. Apply a small amount of silicone-based lubricant to the O-rings
located at the base of the spout. Firmly insert spout assembly into
the top hole of faucet body (approximately 1/4"). You may swivel
the faucet le or right.
Airgap to system drain
(1/4" tubing)
Faucet to drain
saddle (3/8" tubing)
Product water
(1/4" tubing)
Metal base plate
Rubber seal
1
2
3
4
5
Connect to product
water tubing
