This system has been designed for installa on by a licensed professional such as a contractor or plumber. Proper comple on of this installa-
on will require basic familiarity with standard sink plumbing and proper use of common hand and power tools. Improperly installed systems
could result in water damage due to leaks or fl ooding. Do not use with water that is microbiologically unsafe.
Typical Installa on Diagram
A. Product water storage tank
B. Tank shut-off valve
C. Tank tubing
D. Air-gap faucet
E. Drain connec on assembly
F. Drain tubing
G. Quick-connect fi ng
H. Product water tubing
I. Membrane desalinator
J. Carbon post-fi lter
K. Sediment/carbon pre-fi lter
L. Automa c shut-off valve
M. Inlet fi ng
N. Feed water tubing
O. Feed water shut-off
A
B
C
D
E
F
G
I
JK
L
M
N
O
F
H
