WARNING:
Do not connect this grill to any unregulated sources of propane.
Before each use, check the gas hose for excessive abrasion, wear or cuts. Replace a
damaged hose assembly with the one specified in the parts list before using the grill.
Always perform the Leak Test listed below before using your grill for the first time, if
the cylinder has been changed, if any gas supply components have been changed, if
the regulator flow-limiting device has been activated or after a long period of non-use.
Do not attempt to connect this grill to the LP system of a motor home or trailer.
- 18 -
Be sure the LP tank is OFF by turning the hand wheel clockwise until it stops.
Place the tank on the hook under the grill body with the valve facing outward.
See Assembly instructions to secure the tank to the grill body.
Be sure all burner controls are turned to the “OFF” position.
Remove the safety cap from the cylinder valve.
Center the regulator nipple into the cylinder valve.
Turn the black nut clockwise until it stops. Hand tighten Only.
Do not use a wrench.
The regulator must enter the cylinder valve in a straight line.
Center the regulator nipple into the cylinder valve.
GCC 1 Type 1 Connector.
Always keep this gas cylinder in the upright position at all times.
Before store the grill, LP gas cylinder should be disconnected from grill.
Turn off the cylinder to “OFF” position.
Turn clockwise of the GCC 1 Type Connector until separate the gas cylinder and regulator.
The regulator must
enter the cylinder valve
in a straight line.
Center the regulator
nipple into the cylinder
valve.
Always keep the gas cylinder in
the upright position at all times.
Center the regulator
nipple into the cylinder
valve.
1.
2.
3.
4.
5.
6.
1.
2.
3.
TO CONNECT THE CYLINDER TO THE REGULATOR AND HOSE
DISCONNECT THE CYLINDER
Straight
Q.C.C.1 Type Connector
WARNING
