OSEEX206-EN
2/10
VALVES SPECIFICATIONS
Water Oil Air, Gas Steam Chemicals Sea water Slurry Negative pressure
E EG type
Valve type E (Brass) E (Stainless) EG
Design 2 way, Standard port 2 way, Standard port 2 way, Standard port
Connection Threaded End Rc Threaded End Rc Threaded End Rc
Fluid
Max pressure 1 MPa 2 MPa 1 MPa 1 MPa
Size [mm] 015 to 025 032 to 050 008 to 010 015 to 050 015 to 050
Material Body C3771BE SCS14A SCS14A
Ball C3604BD C3771BE SUS316 SCS14A SCS14A
Seat F-PTFE PTFE R-PTFE
Stem seal Packing - - -
O-ring FKM FKM FKM (For steam)
Note) C3771BE (PLTD) / C3604BD (PLTD)
PRESSURE & TEMPERATURE RATING
E (Brass) E (Stainless) EG
INHERENT FLOW CHARACTERISTIC
E / EG
Cv
value
(%)
Valve opening
(%)
Range ability 30:1
